The Worlds First Personal ComputeR |
|
|
Release Date: |
January, 1977, at Consumer Electronics Show in Chicago |
|
CPU |
1 Mhz MOS 6502 |
|
Original Cost |
$795 which is $4,000 in 2024 dollars |
|
RAM Memory |
8 Kb (8192 bytes) |
|
Offline Storage |
Cassette Tape Drive built-in, later floppy disk drives |
|
O/S / ROM: |
18 Kb with COMMODORE BASIC by Bill Gates and Paul Allen |
|
PORTS |
2 Datassette ports, 1 IEEE-488 Parallel Port, Custom User Port |
|
Keyboard |
Chicklet (calculator) keys: no other computers had keyboard |
|
Display |
9” integrated white monochrome monitor 40 x 25 characters |
|
Sound / Game Port |
None (added with home brew modifications via User Port) |
|
Reset Button |
None |
|
|
|
|
Restoration |
|
|
PET Serial Number Project Mother Board |
Link to entry. Manufacture date late 1978 Voltage Regulator replaced, ROM chips pin soldering |
|
System |
Long debugging of hang after 10 min was ROMs problem. |
|
Monitor |
Capacitors replaced |
|
Datassette |
Cleaned and replaced belt, adjusted height of head. |
|
Keyboard |
Used ferrous paint to restore membrane key contact, resoldered wires |
|
|
|
|
Modifications/Add Ons |
|
|
ROM / RAM Replacement |
Tynemouth Software board with selective replacement of RAM/ROM up to 32 KB and Basic 1, Basic 2, and Basic 4 |
|
Sound / Game Port |
Home brew board with CB2 audio out and joystick port. |
|
Music |
Home brew buffered 8-bit audio DAC board + 4 voice S/W |
|
Mass Storage |
PETdisk MAX SD and internet device using Atmel ATmega1284 |
|
Reset Button |
Added home brew push button that ground /RESET line. |
|
PETRock PETpix |
M5Stack M5StickC Plus ESP32 powered spectrum analyzer display Raspberry Pi powered display of video with PETSCII graphics |
|
|
|
|
|
|
|
|
|
